Kumpulan Skema Stereo Ecoder :
Buat yg memiliki pemancar FM agar keluarannya Stereo silahkan di coba salah satu skema di bawah ini
Daf Komponen :
R1 = R5 = 10K
R2 = R6 = 220K R2 = R6 = 220K
R3 = R4 = R9 = 47K R3 = R4 = R9 = 47k
R7 = R8 = 4.7K R7 = R8 = 4.7K
R10 = 68K R10 = 68K
R11 = R12 = 27K R11 = R12 = 27K
R13 = 2.2K variable R13 = 2.2k variabel
R14 = 20K liniar R14 = 20K liniar
C1 = C2 = 1nF C1 = C2 = 1nF
C3 = C4 = C11 = 100nF C3 = C4 = C11 = 100nF
C5 = C10 = 10nF C5 = C10 = 10nF
C6 = 470pF C6 = 470pF
C7 = 100pF C7 = 100pF
C8 = 68pF C8 = 68pF
C9 = 10uF C9 = 10uF
L = 6.8mH L = 6.8mH
IC1 = 4066 IC1 = 4.066
IC2 = 4013 IC2 = 4.013
IC3 = 4047 IC3 = 4.047
IC4 = 741 IC4 = 741
